I wanted to make two functions with delays to assist BP scripting of logic. One for dialog and one for item interaction. The one I’ll cover here handles dialog.
My goal: Make a function that accepts dialog parameters, waits for a user response and returns the player’s selection. (Additionally, make a breakout which flows execution based on the player’s selection.)
I couldn’t find any help online when writing this function. So I crept through engine code. Unreal has a LatentActionManager held by UWorld. You can get its reference from GetWorld->GetLatentActionManager()
Using this I made a c++ class derived from FPendingLatentAction and put our own logic in it.
Here is the BP functions header:
|
1 2 3 4 5 6 7 8 9 10 11 12 |
UFUNCTION(BlueprintCallable, Meta = (ExpandEnumAsExecs = "PlayerSelection"), Category = "Dialog", meta = (Latent, WorldContext = "WorldContextObject", LatentInfo = "LatentInfo")) void CharacterDialog(UObject* WorldContextObject, FString CharactersDialog, FString ResponseOptionA, bool ShowResponseB, FString ResponseOptionB, bool ShowResponseC, FString ResponseOptionC, bool ShowResponseD, FString ResponseOptionD, struct FLatentActionInfo LatentInfo, EActorDialogResults& PlayerSelection); |
Here is the function’s definition:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 |
// //*launch dialog action, which will wait for player response*/ void ABaseCharacter::CharacterDialog(UObject* WorldContextObject, FString CharactersDialog, FString ResponseOptionA, bool ShowResponseB, FString ResponseOptionB, bool ShowResponseC, FString ResponseOptionC, bool ShowResponseD, FString ResponseOptionD, struct FLatentActionInfo LatentInfo, EActorDialogResults& PlayerSelection) { FDialogStruct Dialog = FDialogStruct(DialogPortrait, CharactersDialog, ResponseOptionA, ShowResponseB, ResponseOptionB, ShowResponseC, ResponseOptionC, ShowResponseD, ResponseOptionD); /**launch dialog delay action, which will wait for player response to dialog*/ if (UWorld* World = GEngine->GetWorldFromContextObjectChecked(WorldContextObject)) { FLatentActionManager& LatentActionManager = World->GetLatentActionManager(); if (LatentActionManager.FindExistingAction<FDialogDelayAction>(LatentInfo.CallbackTarget, LatentInfo.UUID) == NULL) { LatentActionManager.AddNewAction(LatentInfo.CallbackTarget, LatentInfo.UUID, new FDialogDelayAction(Dialog, TempReferenceIComponentRequestingDialog, NULL, LatentInfo, PlayerSelection)); } } } |
What happens above, we grab the LatentActionManager and make sure it currently isn’t running a task for this object and pass it our custom latent task, along with our custom latent tasks construction params. InteractionInfo is a custom struct with the players choices, and PlayerSelection is an enum of the possible responses the player can have.
Let’s look at my custom FPendingLatentAction derived class:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 |
#include "UObject/WeakObjectPtr.h" #include "Engine/LatentActionManager.h" #include "LatentActions.h" #include "DialogContainer.h" #include "ActorDialogComponent.h" // Based off FDelayAction // Sends dialog to passed in ActorDialogComponent classes delegate to begin dialog //waits for a response class FDialogDelayAction : public FPendingLatentAction { public: FDialogStruct DialogToProcess; FName ExecutionFunction; int32 OutputLink; FWeakObjectPtr CallbackTarget; UActorDialogComponent* DialogComponentCallback; class UBusterInteractionComponent* IComponentCallback; int32 Count = 0; EActorDialogResults* DialogResults = nullptr; /** * @param DialogComponent - Pointer to DialogComponent that called this function. * @param LatentInfo - latent info for callback */ FDialogDelayAction(const FDialogStruct& Dialog, UBusterInteractionComponent* IComponentCalling, UActorDialogComponent* DialogComponent, const FLatentActionInfo& LatentInfo, EActorDialogResults& PlayerSelection); virtual void UpdateOperation(FLatentResponse& Response) override; void ReceivePlayerSelection(EActorDialogResults PlayerSelection); }; |
Constructor:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 |
#include "DialogDelayAction.h" #include "BusterInteractionComponent.h" FDialogDelayAction::FDialogDelayAction(const FDialogStruct& Dialog, UBusterInteractionComponent* IComponentCalling, UActorDialogComponent* DialogComponent, const FLatentActionInfo& LatentInfo, EActorDialogResults& PlayerSelection) { DialogToProcess = Dialog; ExecutionFunction = LatentInfo.ExecutionFunction; OutputLink = LatentInfo.Linkage; CallbackTarget = LatentInfo.CallbackTarget; DialogComponentCallback = DialogComponent; DialogResults = &PlayerSelection; IComponentCallback = IComponentCalling; //initiate dialog UI b if (IComponentCallback) { *DialogResults = EActorDialogResults::NoSelectionYet; //Send dialog to BusterInteractionComponent that started process, and wait for response IComponentCallback->ReceiveRequestedDialog(Dialog, this); } else { UE_LOG(LogTemp, Warning, TEXT("ERROR W/ I COMPONENT COMPONENT POINTER IN DIALOG DELAY ACTION ")); } } void FDialogDelayAction::UpdateOperation(FLatentResponse& Response) { Response.FinishAndTriggerIf(*DialogResults != EActorDialogResults::NoSelectionYet, ExecutionFunction, OutputLink, CallbackTarget); } void FDialogDelayAction::ReceivePlayerSelection(EActorDialogResults PlayerSelection) { *DialogResults = PlayerSelection; } |
I create a callback (I send a self reference to the actor who called this function.) Once the player has selected input, I push a response to this delayed action.
|
1 2 3 4 |
void FInteractionDelayAction::ReceivePlayerSelection(EInteractionResults PlayerSelection) { *InteractionResults = PlayerSelection; } |
One could also poll from the UpdateOperation. The tick/update function notes a value has been set and completes the task.
|
1 2 3 4 |
void FInteractionDelayAction::UpdateOperation(FLatentResponse& Response) { Response.FinishAndTriggerIf(*InteractionResults != EInteractionResults::NoSelectionYet, ExecutionFunction, OutputLink, CallbackTarget); } |
If you want to break out the response use the ExpandEnumAsExecs UFunction specifier:
|
1 2 3 |
/*EXAMPLE BLUEPRINT INTERACTION SELECTION BREAKOUT*/ UFUNCTION(BlueprintCallable, Category = "Interactable Object", Meta = (ExpandEnumAsExecs = "OutPaths")) void BreakoutInteractionSelection(const EInteractionResults& PlayerSelection, EInteractionResults& OutPaths); |
